With a built-in DSP module inside the XPower, the comes the birth of the 'D' and 'D4' variants of the XPower devices. The 2 in 4 out DSP module holds 40 bit floating point, 96kHz sample rate and 24bit A/D D/A converter, while being controllable remotely with a ACX'ssoftware.
Available as the X2000D, X4000D, X1D, X2000D3, X4000D4, and X1D4.
With DSP module inside XPower, the 2 in 4 out XPower-D is born. The 2 in 4 out DSP module holds 40 bit floating point, 96kHz sample rate and 24 bit A/D D/A converter.
The amplifiers is also available as the XPower D4 which allows for 4 in 4 out channels with Phoenix input. The devices reach a maximum level of +20dBu, and a frequency response of +/-0.1dB (20 to 30kHz), and 115dB dynamic range (unweighted).
Also comes with standard safety locks such as a password system and being able to set 30 presets at a time, which can be set and controlled via the ACX Console using a USB or Ethernet.
| MODEL | X2000N | X4000N | X1N |
| Input Port | RJ45x1 | RJ45x1 | RJ45x1 |
| Output Port | SpeakON*4 | SpeakON*4 | SpeakON*4 |
| Output power (1%THD+N,1kHz @42) | 500W | 1000W | 2500W |
| Output power (1%THD+N,1kHz @8Q) | 250W | 500W | 1750W |
| Total system efficiency (2x250W @82) | 89% | 88% | 88% |
| Peak Output Current | 30A | 30A | 30A |
| THD+N (1kHz @1W) | 0.003% | 0.003% | 0.05% |
| Dynamic range | 120dB(A) | 120dB(A) | 120dB(A) |
| Signal to Noise-Ratio | >120dB | >120dB | >120dB |
| 8 ohms laod,1 kHz and below | >1000 | >1000 | >1000 |
| ldle Noise | 40μV(A) | 40μV(A) | 110μV(A) |
| Output impedance (1kHz) | 14mΩ | 14mΩ | 11mΩ |
| Main input voltage | 90VAC-240VAC | 90VAC-240VAC | 90VAC-240VAC |
| Power Supply | PowerCON*1 | PowerCON*1 | PowerCON*1 |
| Standby consumption | 0.3W | 1.2W | 6W |
| Dimension | 483x388x88mm | 483x388x88mm | 483x469x88mm |
| Weight | 6.1kg | 7.1kg | 12.6kg |
