PoE16++ Switch

The PoE16++ Switch is a full gigabit BT PoE Switch with adaptive RJ45 ports and 2 1000M SFP optical port slots.
Among them, 1-16 ports support ultra high power 71W POE output and are backward compatible with IEEE 802.3af/at PoE standard, with a single port PoE power of up to 95W.
Providing a combination of Gigabit Ethernet port+Gigabit independent optical port, this switch makes it convenient for users to flexibly network and meet their various network needs for any installation application.

The POE16++ series is a full gigabit BT PoE switch with 16 10/100/1000M adaptive RJ45 ports and 2 1000M SFP optical port slots.

As a PoE power supply device, it can automatically detect and identify power receiving devices that meet the standards and provide power to them through network cables. It can provide stable, safe, and reliable power

output and data transmission for PTZ network players, high-power wireless APs, high-power network multimedia speakers, high-power POE lighting and other terminals through network cables, meeting the demand for high-density PoE power supply in network environments.

It is suitable for hotels, campuses, parks, supermarkets, scenic spots, factory dormitories, and SMB small and medium-sized enterprises to form an economical and efficient network. Non network management models,plug and play, no configuration required, simple and convenient to use.

its 16 10/100/1000Base-T RJ45 ports support BT PoE power supply, meets the requirements of security monitoring, telephone  conference system, and wireless coverage the demand for high-power PoE power supply in scenarios such as covers. The maximum output power of any single port is up to 95W, and is backwards compatible with IEEE 802.3af/at PoE power supply standard, automatically identifying PoE devices for power supply, do not damage non PoE devices. Notably, the device supports a priority mechanism, supplying power only as necessary and will prioritize power to the ports that need it the most to avoid equipment overload with a total wattage of 1200w.


Port Characteristics
Fixed Port16 10/100/1000Base TPOE ports (Data/Power), 2 1000Base XSFP uplink optical port slots (Data)
Network port1-16 port 10/100/1000Base-T (X) automatic detection, full/half duplex MDI/MDI-X adaptive
Twisted pair transmission10BASE-T: Cat3,4,5 UTP(≤100 meter)
100BASE-TX: Cat5 or later UTP(≤100 meter)
1000BASE-T: Cat5e or later UTP(≤100 meter)
Optical cableMulti mode  - working wavelength: 850nm, transmission distance: 0-500M;
Single mode - working wavelength: 1310nm, transmission distance: 0-40KM;
                   working wavelength: 1550nm, transmission distance: 0-120KM
Chip parameters
Network ProtocolIEEE802.3 10BASE-T; IEEE802.3i10Base-T;
IEEE802.3u 100Base-TX;
IEEE802.3ab 1000Base-T;
IEEE802.3z 1000Base-X;
IEEE802.3x
Forwarding mode
PoE and Power
PoE Port1-16 ports support IEEE802.3bt, backward compatible with IEEE802.3af/at standard POE power supply
Power Supply PinDefault support for 1/2,4/5 (+)&3/6,7/8 (-) 8-core power supply
Maximum single port PoE power95W, standard IEEE802.3af/at/bt; when 16 ports used simultaneously, average maximum power per port is 71W
Total power/input voltage)1200W(AC100-240V)
Overall power consumption)Standby power:<25W; Fully loaded power:<1200W
Supporting power supply)(Internal Power Supply,AC:100~240V 50-60Hz6.6A) x 2
Physical parameters
External dimensions(LxWxH):440x378x44.3mm
Weight / Net Weight <5.0kg/<5.8kg
