CS Series

CS 3" Active Column with Dante

Carries the same benefits of the CS3 passive series, but its satellite channel power output helps to simplify setup, while keeping everything you need from quality speakers with a full-range of sound.
Comes in 6 different models, the CS342A, CS342AN CS382A, CS382AN, CS3122A, and the CS3122 AN with several accessories for installation, and fine-tuning its angles. Also available in black or white

CS3 Active Speaker has everything the Passive speaker does, with the added benefit of even less setup required. The addition of its satellite channel power output makes setup and maintenance a breeze, while still offering the same quality of sound perfect for sound reinforcement where needed with little prep.

Its compact size allows the entire system to run efficiently and provides a simple yet effective solution for a variety of fixed sound reinforcement installation systems. This is done through its Aluminum-magnesium alloy-based body,implanted with 3"woofer along with 3"and 4"aluminum treble,brings out a stylish and magnificent appearance. Unlike regular speaker designs,CS selection of the aluminum treble maximizes its performance on wonderful sound quality and smooth trele. It is excellent in medium-sized application.

The CS3" series is perfect for various installations, from smaller indoor locations to medium-sized areas like sections of malls, sports centers, concert halls and more.

Comes with multiple installation combinations through its adjustable hanging accessories, the CS series is applicable to any environment.

 ModelCS342A
CS342AN
CS382A
CS382AN
CS3122A
CS3122AN
 components4×3"bass
3"treble
8×3"bass
4"treble
12×3"bass
4"treble
 Freq.Resp110 Hz-20 KHz110 Hz-20 KHz110 Hz-20 KHz
 Max SPL114dB119dB122dB
 Coverage90°×40*90°×40°90°×40
 Power Amp250W500W500W
 Power90V-240V AC90V-240V AC90V-240V AC
 Input

CSA:XLR×1/PowerCON×1

CSAN:EtherCON×1/PowerCON×1

 OutputXLR×1XLR×1XLR×1
 ColorBlack/WhiteBlack/WhiteBlack/White
 AccessoriesWall/HangerWall/HangerWall/Hangel
 W×D×H(mm)124×148×66C124×148×1072124×148×1382
 Net WeightCS342A-6.8kg
CS342AN -7kg
CS382A-11.6kg
CS382A-11.8kg
CS3122A-14.6kg
CS3122A-14.8ko
